theMova S360-100 WH GST
Модель:
4829Артикул:
1030570Наличие:
Есть в наличии
0.00 LEI
-15°C ... 50°C
Impact resistance250 W
Type of connectionFunction description
- Motion detector (PIR), with pre-configured cable and Wieland GSTi18 connector, cable length 1,50 meter
- Passive infra-red motion detector for ceiling installation in false ceilings
- Circular detection area 360°, up to Ø 8 m (50 m2) at mounting height 3 m
- 1 channel light (Relay 230 V)
- Automatic motion and brightness-dependent control for lighting
- Daylight sensor mode for brightness-dependent control of the lighting, switchable via app
- Mixed light measurement
- Operation as fully automatic device
- Brightness switching value configurable, teach-in function
- Pulse function for staircase light time switch
-15°C ... 50°C
Impact resistance250 W
Type of connection360°
Ambient temperature50 m² (ø 8 m | 360°)
Detection angleColour
WhiteCompact and flourescent lamps
1150 VA (cos φ = 0,5)Frequency
50 HzIK04
Type of protectionIncandescent/halogen lamp load
2300 WInrush current
max. 400 A / 200 µsInstallation height
2 - 4 mInstallation type
Ceiling installation, IndoorIP 54 (when fitted)
Lamp types
Incandescent/halogen lamps, fluorescent lamps, Energy saving lamps, LEDsLED lamp 25 W
LED lamp 2-8 WLight
Detection rangeLight measurement
Mixed light measurementLight switch-off delay
10 s - 60 minOperating voltage
230 V ACPower consumption
~0.5 WSetting range brightness
30 - 3000 lxSpring terminals
Switching outputType of contact light
Relay 230 V/10 A µ-contactОтзывов: 0
