thePassa P360 KNX UP WH
Модель:
4791Артикул:
2019300Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-15°C ... 50°CColour
WhiteFunction description
- Passive infra-red presence detector KNX for flush-mounted ceiling installation
- Rectangular detection area 360°, 30 x 4,5 m, (135 m2) at mounting height 3 m, for corridors and storage areas, with 2 individually connectable and disconnectable detection zones
- 2 channels light and 2 channels presence
- 2 channel light C1, C2 with 2 light measurements
- 2 presence channels can be parametrized individually
- Adaptable 2 channel light measurement
- Function aura effect, switches on the lighting group when there is a person in its detection area and dims the adjacent lighting groups
- Function chaser light, recognises the direction of movement of the people in the room and "predictively" switches on the adjacent lighting group
- Function walking direction recognition
- Mixed light measurement suitable for LEDs, fluorescent lamps (FL/PL/ESL) and halogen/incandescent lamps
Ambient temperature
-15°C ... 50°CColour
WhiteDetection angle
360°Detection range
150 m² (30,0 x 5 m)Installation height
2 - 6 mInstallation type
Ceiling installationLamp types
Energy saving lamps, fluorescent lamps, Incandescent/halogen lamps, LEDsLight measurement
Mixed light measurementLight switch-off delay
30 s - 60 minMaximum height
15 mMeasuring range brightness
10 - 3000 lxMinimum height
1.7 mPresence switch-off delay
10 s - 120 minSwitch-on delay presence
10 s - 30 min / inactiveType of connection
KNX bus terminalType of protection
IP 54 (when fitted)Отзывов: 0
