thePrema S360-100 E UP BK
Модель:
4759Артикул:
2070602Наличие:
Есть в наличии
4302.00 LEI
0°C ... 50°C
Impact resistance360°
Ambient temperatureFunction description
- Passive infra-red presence detector for flush-mounted ceiling installation
- Square detection area 360°, 7 x 7 m, (49 m2) at mounting height 3 m
- 1 channel light (Relay, 230 V)
- Automatic presence- and brightness-dependent control for lighting
- Mixed light measurement suitable for fluorescent lamps (FL/PL/ESL), halogen/incandescent lamps and LEDs
- Choice of fully or semi-automatic operation
- Adjustable brightness switching value, teach-in function
- Self-learning time delay
- Connection option for sensors or switches for manual switching with automatic recognition of sensor/switch
- Pulse function for staircase light time switch
0°C ... 50°C
Impact resistance360°
Ambient temperature49 m² (7,0 x 7,0 m)
Detection angle55 mm
Switching output600 W
Type of connectionColour
BlackCompact and flourescent lamps
1150 VA (cos φ = 0,5)Energy saving lamps
16 x 54/58 W, 24 x 35/36 W, 8 x 2 x 54/58 W, 12 x 2 x 35/36 WFrequency
50 - 60 HzIK04
Type of protectionIncandescent/halogen lamp load
2300 WInrush current
max. 800 A / 200 µsInstallation height
2 - 3.5 mInstallation type
Ceiling installationIP 40 (when fitted)
Lamp types
Incandescent/halogen lamps, fluorescent lamps, Energy saving lamps, LEDsLED lamp 60 W
LED lamp 2-8 WLight
Detection rangeLight measurement
Mixed light measurementLight switch-off delay
10 s - 60 minmax. 2 x 2,5 mm²
Size of concealed housingMinimum height
1.7 mOperating voltage
110 V AC - 230 V AC ± 10 %Power consumption
~0.1 WScrew terminals
Max. cable cross sectionSetting range brightness
5 - 3000 lxType of contact light
Relay 230 V/10 A µ-contactОтзывов: 0
