theRonda P360-100 WH GST
Модель:
4833Артикул:
2080010Наличие:
Есть в наличии
0.00 LEI
-15°C ... 50°C
Type of protection360°
Ambient temperatureFunction description
- Presence detector (PIR), with pre-configured cable and Wieland GSTi18 connector, cable length 1,50 meter
- Passive infrared presence detector for ceiling mounting
- Round detection area 360°, up to Ø 24 m (452 m2)
- Automatic presence- and brightness-dependent control for lighting
- Mixed light measurement suitable for fluorescent lamps (FL/PL/ESL), halogen/incandescent lamps and LEDs
- Channel A, light: relay, 230V
- Adjustable brightness switching value, teach-in function
- Reduction of switch-off delay time in the event of short presence (brief-presence)
- Pulse function for staircase light time switch
- Sensitivity adjustable
-15°C ... 50°C
Type of protection360°
Ambient temperature600 W
Type of connectionColour
WhiteCompact and flourescent lamps
1150 VA (cos φ = 0,5)Frequency
50 - 60 HzIncandescent/halogen lamp load
2300 WInstallation height
2 - 10 mInstallation type
Ceiling installationIP 54 (when fitted)
Lamp types
Incandescent/halogen lamps, fluorescent lamps, Energy saving lamps, LEDsLED lamp 60 W
LED lamp 2-8 WLight
Detection angleLight measurement
Mixed light measurementLight switch-off delay
10 s - 60 minmax. 2 x 2,5 mm²
Switching outputMinimum height
1.7 mOperating voltage
110 V AC - 230 V ACPower consumption
~0.15 WScrew terminals
Max. cable cross sectionSetting range brightness
30 - 3000 lxОтзывов: 0
