AMUN 716 SO
Модель:
5382Артикул:
7160820Наличие:
Есть в наличии
0.00 LEI
Display
6 LEDsInstallation type
Wall installation (also on flush-mounted socket possible)Function description
- CO2 sensor
- Suitable for conference and meeting rooms, offices, schools/nurseries, passive and low-energy housing.
- For fan control
- Warning display for CO2 concentration
- Power unit optionally available, power unit is suitable for flush mounted installation
- Simple upgrade of uncontrolled ventilation systems possible
- 3 x 0–10 V outputs for CO2, temperature and relative humidity
Display
6 LEDsInstallation type
Wall installation (also on flush-mounted socket possible)Measuring range CO2
0 - 5000 ppmMeasuring range humidity
30 - 80 % rFMeasuring range temperature
5°C ... 40°CON/OFF thresholds
700 ppm ±200 ppm, 1300 ppm ±200 ppmOperating voltage
24 V AC/DC SELVOutput
3 x 0-10 VProtection class
II according to EN 60 730-1Type of connection
Screw terminalsType of protection
IP 20Отзывов: 0
