SUL 188 g
Модель:
4924Артикул:
1880033Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-20°C ... 55°CDrive
Quartz-controlled stepper motorFunction description
- Analogue time switch
- Daily program
- 2 channels
- Fine adjustment to set the time to the minute
- Shortest switching time: 30 minutes
- 10 tappets included in delivery
- With power reserve (NiMH rechargeable battery)
- Quartz controlled
- Tappets
- Screw terminals
Ambient temperature
-20°C ... 55°CDrive
Quartz-controlled stepper motorFrequency
45 - 60 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
DIN railNumber of channels
2Operating voltage
230 V ACPower reserve
3 daysProgram
Daily programProgrammable every
15 minProtection class
II according to EN 60 730-1Shortest switching times
30 minStand-by consumption
0.5 WSwitching capacity at 250 V AC, cos φ = 0,6
4 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTest approval
VDETime accuracy at 25 °C
≤ ± 1 s/day (quartz)Type of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Width
3 modulesОтзывов: 0
