TM 179 h
Модель:
4570Артикул:
1790008Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CDrive
Synchronous motorFunction description
- Analogue time switch
- 60 minute program
- 1 channel
- Without power reserve
- Synchronised with mains
- Tappets
- Shortest switching time: 75 seconds
- Switching preselection
- Switching status display
- 6 tappets included in delivery
Ambient temperature
-10°C ... 55°CDrive
Synchronous motorFrequency
50 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
1Operating voltage
230 V ACProgram
60 minutes programProgrammable every
18.5 sProtection class
II according to EN 60 730-1Shortest switching times
1.25 minStand-by consumption
0.9 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTest approval
EMVTime accuracy at 25 °C
Synchronised with mainsType of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Отзывов: 0
