SYN 269 h
Модель:
4643Артикул:
2690008Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CDrive
Synchronous motorFunction description
- Analogue time switch with daily or weekly program (switching disc can be turned)
- 1 channel
- Without power reserve
- Synchronised with mains
- Switching preselection
- Permanent ON/OFF switch
- Simple summer/winter time correction
- Time can be changed clockwise or anti-clockwise
- 32 tappets included in delivery
- Tappets
Ambient temperature
-10°C ... 55°CDrive
Synchronous motorFrequency
50 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
1Operating voltage
230 V ACProgram
Daily program, Weekly programProgrammable every
5 min, 30 minProtection class
II according to EN 60 730-1Shortest switching times
20 min, 2 hStand-by consumption
0.9 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTime accuracy at 25 °C
Synchronised with mainsType of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Отзывов: 0
