SUL 289 h
Модель:
4644Артикул:
2890008Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFunction description
- Analogue time switch with daily or weekly program (switching disc can be turned)
- 1 channel
- With power reserve (NiMH rechargeable battery)
- Quartz controlled
- Switching preselection
- Permanent ON/OFF switch
- Simple summer/winter time correction
- Time can be changed clockwise or anti-clockwise
- 32 tappets included in delivery
- Tappets
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFrequency
50 - 60 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
1Operating voltage
230 V ACPower reserve
3 days full power reserve approx. 3 days after connection to operating voltageProgram
Daily program, Weekly programProgrammable every
5 min, 30 minProtection class
II according to EN 60 730-1Shortest switching times
20 min, 2 hStand-by consumption
0.5 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTime accuracy at 25 °C
≤ ± 1 s/day (quartz)Type of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Отзывов: 0
