SUL 189 s
Модель:
4647Артикул:
1890801Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFunction description
- Analogue time switch
- 1 channel
- With power reserve (NiMH rechargeable battery)
- Quartz controlled
- Daily program
- 96 switching segments
- Shortest switching time: 15 minutes
- Clock hands for time display
- Switching preselection
- Permanent ON/OFF switch
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFrequency
50 - 60 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
1Number of switching segments
96Operating voltage
230 V ACPower reserve
3 days full power reserve approx. 3 days after connection to operating voltageProgram
Daily programProgrammable every
15 minProtection class
II according to EN 60 730-1Shortest switching times
15 minStand-by consumption
0.5 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTest approval
EMVTime accuracy at 25 °C
≤ ± 1 s/day (quartz)Type of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Отзывов: 0
