SUL 189 hw
Модель:
4649Артикул:
1890108Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CFrequency
50 - 60 HzFunction description
- Analogue time switch
- Daily/weekly program and 1/2 day OFF function for the weekdays
- 1 channel (with series connection of 2 the contacts)
- With power reserve (NiMH rechargeable battery)
- Quartz controlled
- Tappets and turning segments
- Shortest switching time: 30 minutes (12 hours for the 1/2 day OFF function)
- Switching status display
- 6 tappets included in delivery
Ambient temperature
-10°C ... 55°CFrequency
50 - 60 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
1Operating voltage
230 V ACPower reserve
3 days full power reserve approx. 3 days after connection to operating voltageProgram
Daily programProgrammable every
15 min, 12 hProtection class
II according to EN 60 730-1Shortest switching times
30 min, 12 hStand-by consumption
~0.5 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
10 ASwitching output
Potential-free and phase-independentTest approval
EMVTime accuracy at 25 °C
≤ ± 1 s/day (quartz)Type of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 20Отзывов: 0
