SUL 285/2 T
Модель:
4650Артикул:
2850033Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFunction description
- Analogue tariff time switch with daily program
- 2 channels
- With power reserve (exchangeable NiMH rechargeable battery)
- Quartz controlled
- Tappets
- Shortest switching time: 20 minutes
- Clock hands for time display
- Switching status display
- Simple summer/winter time correction
- Time can be changed clockwise or anti-clockwise
Ambient temperature
-10°C ... 55°CDrive
Quartz-controlled stepper motorFrequency
50 - 60 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Front panel installation/wall installationNumber of channels
2Operating voltage
110 - 230 V ACPower reserve
6 days full power reserve approx. 3 days after connection to operating voltageProgram
Daily programProgrammable every
5 minProtection class
II according to EN 62 054-21Shortest switching times
20 minStand-by consumption
0.6 WSwitching capacity at 250 V AC, cos φ = 0,6
2 ASwitching capacity at 250 V AC, cos φ = 1
6 ASwitching output
Potential-free and phase-independentTime accuracy at 25 °C
≤ ± 1 s/day (quartz)Type of connection
Screw terminalsType of contact
Changeover contactType of protection
IP 54Отзывов: 0
