theben-timer 26 safety-plus
Модель:
4651Артикул:
0260833Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-40°C ... 55°CFrequency
50 HzFunction description
- Analogue plug-in timer
- Daily program
- With shutter, reduces the risk of people coming into contact with live parts of the socket outlet contact with live parts of the socket and possibly receive an electric shock
- 1 channel
- Synchronised with mains, without power reserve
- Use with earthed sockets
- Switching preselection and switching status display
- 96 switching segments
- Shortest switching time: 15 minutes
Ambient temperature
-40°C ... 55°CFrequency
50 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
Plug-inNumber of channels
1Number of switching segments
96Operating voltage
230 V ACProgram
Daily programProgrammable every
15 minProtection class
II according to EN 60 730-1Shortest switching times
15 minStand-by consumption
~0.8 WSwitching capacity at 250 V AC, cos φ = 0,6
4 ASwitching capacity at 250 V AC, cos φ = 1
16 ATime accuracy at 25 °C
Synchronised with mainsType of connection
Plug-inType of contact
NO contactType of protection
IP 20Отзывов: 0
