TC 649 C
Модель:
4900Артикул:
6490430Наличие:
Есть в наличии
0.00 LEI
Ambient temperature
-25°C ... 55°CFrequency
50 HzFunction description
- Digital time switch / astronomical time switch with weekly program and annual program
- With integrated web server, external operation via app possible via a cloud solution
- Time switching or astronomical programs can be sent to a single device via the cloud and direct switching can be performed via the cloud
- Via the cloud, the control box can be operated from any computer or smartphone and tablet with the Obelisk top3 app and internet access
- An additional network router or GSM, UMTS or LTE router is required to connect to the cloud
- 4 channels
- 800 memory programs
- Channel 1 to 4 can be switched over as time or astro time switch program
- 3 special programs per channel: switching program / astro program; Duration Off; Duration Each with year date function
- Local holidays, fixed date ranges, recurring date ranges and Easter-themed holidays
Ambient temperature
-25°C ... 55°CFrequency
50 HzHousing and insulation material
High-temperature resistant, self-extinguishing thermoplasticInstallation type
DIN railNumber of channels
4Operating voltage
230 V ACProgram
Yearly program, Astronomical programProgram functions
ON-OFF, PulseProtection class
IIShortest switching times
1 sStand-by consumption
~3 WSwitching capacity at 250 V AC, cos φ = 1
6 ASwitching capacity min.
ca. 1 mAType of protection
IP 30Width
4 modulesОтзывов: 0
