LUNA 127 star S
Модель:
4974Артикул:
1270900Наличие:
Есть в наличии
0.00 LEI
-35°C ... 55°C
Type of protection600 W
Housing and insulation materialFunction description
- Twilight switch with integrated light sensor
- Test function
- Teach-in function
- Timer function (1 hour on)
- Switchable brightness range: 2-100/ 100-2000 lux
- Cable feed from the back and from below
- Cover with snap-on function when opening for the straightforward installation of the device
- Captive screws
- Large terminal area
- Brightness value can be set without opening the device
-35°C ... 55°C
Type of protection600 W
Housing and insulation materialFrequency
50 - 60 HzHalogen lamp load
2300 WHigh-temperature resistant, self-extinguishing thermoplastic
Ambient temperatureII
Incandescent/halogen lamp load
2300 WInstallation type
Wall installation or mast bracketIP 55
Protection classLED lamp 50 W
LED lamp 2-8 WNumber of channels
1Operating voltage
230 V ACSetting range brightness
2 - 2000 lxStand-by consumption
~0.7 WSwitch-off delay
2 - 100 sSwitch-on delay
2 - 100 sSwitching capacity
16 A at 230 V AC, cos φ = 1, 10 AX at 230 V AC, cos φ = 0.3Switching output
Not potential-free (230 V)Type of connection
Screw terminalsType of contact
NO contactОтзывов: 0
