TM 345 B
Модель:
4946Артикул:
3450730Наличие:
Есть в наличии
0.00 LEI
10 mA - 20 A
Sett
0.1 s - 100 h 7 ranges8 A
Switching outputFunction description
- Electronic time relay
- With flip-flop function
- Pulse and break time independently adjustable
- Can be used universally for controlling automatic processes in machines, lighting, ventilation, heating, cupboards etc.
- Precise analogue time setting
- Multi-voltage input for all supply and control voltages, no jumpers or additional terminals are required
- LED to display the switching status
10 mA - 20 A
Sett
0.1 s - 100 h 7 ranges8 A
Switching outputAmbient temperature
-20°C ... 60°CElectrical service life
105 operating cyclesFall back value of nominal input voltage
20.4Frequency
50 - 60 HzHigh-temperature resistant, self-extinguishing thermoplastic
Switching capacity at 250 V AC, cos φ = 1Opening width
Housing and insulation materialOperating voltage
24 V AC - 240 V AC / 24 V DCPotential-free
Nominal currentProtection class
IIRepeat accuracy
± 0.5 % at constant parametersStand-by consumption
1 WType of contact
Changeover contactType of protection
IP 20Width
1 modulesОтзывов: 0
