Duomo IP65 / IP20

Combine an elevated luminous flux with an excellent visual comfort: this is the virtue of Duomo. Its recessed LED and its optical glass lense reduce the luminaires UGR value and its ant-glare lampshade disminishes reflections. Duomo is convenient for applications with big ceiling heights and projects with high light level requirements. Conceived to cover demands of general lighting, its conical light distribution offers a very uniform lighting.

• Luminous flux

  2450 lm / 2500 lm / 5100 lm / 5200 lm

• Lighting efficiency

  80%

• Power

  16,5 W / 41 W

• Dimming

  No Dim, DALI, Push

• Color temperature

  3000K / 4000K

• Sealing

  IP65/20

• Chromatic stability

  MacAdam Step 2

• Recess measurements

  Ø177mm

• Light beam angle

  42°

• DUOMO IP65 1 3000K W

  A2850111W

  White

  LED

  2450 lm

  16,5 W

  3000K

  CRI>90

  42°

  80%

  No Dim

  IP65/20
• DUOMO IP65 1 4000K W

  A2850112W

  White

  LED

  2500 lm

  16,5 W

  4000K

  CRI>90

  42°

  80%

  No Dim

  IP65/20
• DUOMO IP65 2 3000K W

  A2850211W

  White

  LED

  5100 lm

  41 W

  3000K

  CRI>90

  42°

  80%

  No Dim

  IP65/20
• DUOMO IP65 2 4000K W

  A2850212W

  White

  LED

  5200 lm

  41 W

  4000K

  CRI>90

  42°

  80%

  No Dim

  IP65/20
• DUOMO IP65 2 DIM PUSH 3000K W

  A2850221W

  White

  LED

  5100 lm

  41 W

  3000K

  CRI>90

  42°

  80%

  Push

  IP65/20
• DUOMO IP65 2 DIM PUSH 4000K W

  A2850222W

  White

  LED

  5200 lm

  41 W

  4000K

  CRI>90

  42°

  80%

  Push

  IP65/20
• DUOMO IP65 2 DIM DALI 3000K W

  A2850241W

  White

  LED

  5100 lm

  41 W

  3000K

  CRI>90

  42°

  80%

  DALI

  IP65/20
• DUOMO IP65 2 DIM DALI 4000K W

  A2850242W

  White

  LED

  5200 lm

  41 W

  4000K

  CRI>90

  42°

  80%

  DALI

  IP65/20
