SMG 2 S KNX
Модель:
5175Артикул:
4910273Наличие:
Есть в наличии
0.00 LEI
-5°C ... 45°C
Type of protection1 - 10 V
Signal current input max.Function description
- 2-way 1-10 V control unit MIX
- Base module MIX
- Can be upgraded to maximum of 6 channels
- Free combination of switches, dimming, blinds and heating control as well as binary inputs
- Switching and dimming of lighting circuits in combination with electronic ballasts (EBs and ballasts LED)
- 1-10V inputs and one switch output (relay contact) per channel
- LED switching status display for each channel
- Manual switch with On/Off/Bus settings (also without bus voltage)
- With crossover switching to spare the relay contact
-5°C ... 45°C
Type of protection1 - 10 V
Signal current input max.100 mA
Signal duration140 µF
Voltage input230 V AC
Frequency output2500 W
Capacitive load3680 W
Incandescent/halogen lamp load400 A (150 µs), 200 A (600 µs)
Resistive load50 Hz
Inrush current500 m
Ambient temperatureCapacity loss max.
2.4 WContinuous
Max. cable lengthFrequency
50 HzII according to EN 60 730-1
Installation type
DIN railIP 20
Protection classMax. cable cross section
Solid wire: 0.5 mm² (Ø 0.8) to 6 mm² | Stranded wire with end sleeve: 0.5 mm² to 4 mm²Number of channels
2Opening width
Switching outputOperating voltage
230 V AC, 50 HzOperating voltage KNX
Bus voltage, ≤10 mAPotential-free
Voltage outputStand-by consumption
1.6 WType of connection
Terminal screws | Bus connection: KNX bus terminalType of contact
NO contact, 16 A, 10 AWidth
4 modulesОтзывов: 0
