Deep Mini
Deep is a family of LED downlights for general lighting functions that stands out for its attractive appearance, where the diffuser is distinctly recessed in relation to the level of the perimeter frame. With its different sizes, it adapts to each project’s requirements and adds a differentiating attribute.
Luminous flux
975 lm / 1050 lm / 1075 lm / 1275 lm / 1375 lm / 1400 lm
Lighting efficiency
76%
Power
7 W / 10 W
Dimming
No Dim, DALI, Push
Color temperature
2700K / 3000K / 4000K
Sealing
IP43 / IP54
Chromatic stability
MacAdam Step 2
Recess measurements
Ø122mm
Light beam angle
89°
A2500210WT
Textured white
LED
975 lm
7 W
2700K
CRI>90
89°
76%
No Dim
IP43
A2500211WT
Textured white
LED
1050 lm
7 W
3000K
CRI>90
89°
76%
No Dim
IP43
A2500212WT
Textured white
LED
1075 lm
7 W
4000K
CRI>90
89°
76%
No Dim
IP43
A2500220WT
Textured white
LED
975 lm
7 W
2700K
CRI>90
89°
76%
Push
IP43
A2500221WT
Textured white
LED
1050 lm
7 W
3000K
CRI>90
89°
76%
Push
IP43
A2500222WT
Textured white
LED
1075 lm
7 W
4000K
CRI>90
89°
76%
Push
IP43
A2500240WT
Textured white
LED
975 lm
7 W
2700K
CRI>90
89°
76%
DALI
IP43
A2500241WT
Textured white
LED
1050 lm
7 W
3000K
CRI>90
89°
76%
DALI
IP43
A2500242WT
Textured white
LED
1075 lm
7 W
4000K
CRI>90
89°
76%
DALI
IP43
A2500310WT
Textured white
LED
1275 lm
10 W
2700K
CRI>90
89°
76%
No Dim
IP43
A2500311WT
Textured white
LED
1375 lm
10 W
3000K
CRI>90
89°
76%
No Dim
IP43
A2500312WT
Textured white
LED
1400 lm
10 W
4000K
CRI>90
89°
76%
No Dim
IP43
