Stram Prismatic
A recessed downlight with one bezel, with marked presence. In the Prismatic version you will discover the attractive and efficient effect of its diffusor’s light waves which, in addition, reduces the UGR.
Awards
Delta Awards´14 Selected
Luminous flux
1525 lm / 1650 lm / 1675 lm / 2100 lm / 2275 lm / 2300 lm / 2800 lm / 3025 lm / 3075 lm / 4050 lm / 4100 lm
Lighting efficiency
87% / 89%
Power
10,5 W / 15,5 W / 22 W / 27 W
Dimming
No Dim, DALI, Push
Color temperature
2700K / 3000K / 4000K
Sealing
IP43/54**
Chromatic stability
MacAdam Step 2
Recess measurements
Ø205mm
Light beam angle
93°
A1980110WT
Textured white
LED
1525 lm
10,5 W
2700K
CRI>90
93°
87%
No Dim
IP43/54**
A1980111WT
Textured white
LED
1650 lm
10,5 W
3000K
CRI>90
93°
87%
No Dim
IP43/54**
A1980112WT
Textured white
LED
1675 lm
10,5 W
4000K
CRI>90
93°
87%
No Dim
IP43/54**
A1980120WT
Textured white
LED
1525 lm
10,5 W
2700K
CRI>90
93°
87%
Push
IP43/54**
A1980121WT
Textured white
LED
1650 lm
10,5 W
3000K
CRI>90
93°
87%
Push
IP43/54**
A1980122WT
Textured white
LED
1675 lm
10,5 W
4000K
CRI>90
93°
87%
Push
IP43/54**
A1980140WT
Textured white
LED
1525 lm
10,5 W
2700K
CRI>90
93°
87%
DALI
IP43/54**
A1980141WT
Textured white
LED
1650 lm
10,5 W
3000K
CRI>90
93°
87%
DALI
IP43/54**
A1980142WT
Textured white
LED
1675 lm
10,5 W
4000K
CRI>90
93°
87%
DALI
IP43/54**
A1980210WT
Textured white
LED
2100 lm
15,5 W
2700K
CRI>90
93°
87%
No Dim
IP43/54**
A1980211WT
Textured white
LED
2275 lm
15,5 W
3000K
CRI>90
93°
87%
No Dim
IP43/54**
A1980212WT
Textured white
LED
2300 lm
15,5 W
4000K
CRI>90
93°
87%
No Dim
IP43/54**
